Product Description Cost-effective solution that provides high bandwidth & transmission rates over longer distances. With LC to ST termination, this high quality fibre optic patch cable is specifically designed for Gigabit Ethernet applications. The Low Smoke Zero Halogen (LSZH / LS0H) jacket is composed from materials that lessen the smoke & halogen emissions when the cable is exposed to extreme temperatures. This reduces the amount of harmful toxic & corrosive gases that cabling made with plastic materials would otherwise emit into the air during combustion. This construction makes LSZH cables ideal to be used where the protection of people & equipment from harmful corrosive gases is absolutely critical. Connectors: • LC Connector Dimensions: 10.75mm Height x 12.5mm Width x 50mm Depth (with installed duplex clip) • ST Connector Dimensions: 9.8mm Height x 19.6mm Width x 59mm Depth Cables: • Maximum Connector Loss: 0.50 d B • Typical Connector Loss: 0.30 d B • Typical Return Loss: -55 d B • Buffer

Material: PVC • Buffer OD: 900 µm • Jacket

Material: LSZH PVC (OFNR riser-rated) • Jacket OD: 1.8 mm • Installation Tensile Load: 100 N (445 lbs) • Long-Term Tensile Load: 50 N (222 lbs) • Maximum Tensile Load: 100 N/cm • Installation (Loaded) Minimum Bend Radius: 5.0cm (1.97in) • Long-Term (Unloaded) Minimum Bend Radius: 3.0cm (1.2in) • Crush Resistance: 750 N/cm • Impact Resistance: 1, 000 cycles • Flex Resistance: 5, 000 cycles • Attenuation at 1550 nm: 0.25 d B/km • Attenuation at 1310 nm: 0.35 d B/km • Operating Temperature: -20°C to +70°C The patented injection moulding process provides each connection greater durability in resisting pulls, strains & impacts from cabling installs. Connectors: • LC Connector Dimensions: 10.75mm Height x 12.5mm Width x 50mm Depth (with installed duplex clip) • ST Connector Dimensions: 9.8mm Height x 19.6mm Width x 59mm Depth Cables: • Maximum Connector Loss: 0.50 d B • Typical Connector Loss: 0.30 d B • Typical Return Loss: -55 d B • Buffer

Material: PVC • Buffer OD: 900 µm • Jacket

Material: LSZH PVC (OFNR riser-rated) • Jacket OD: 1.8 mm • Installation Tensile Load: 100 N (445 lbs) • Long-Term Tensile Load: 50 N (222 lbs) • Maximum Tensile Load: 100 N/cm • Installation (Loaded) Minimum Bend Radius: 5.0cm (1.97in) • Long-Term (Unloaded) Minimum Bend Radius: 3.0cm (1.2in) • Crush Resistance: 750 N/cm • Impact Resistance: 1, 000 cycles • Flex Resistance: 5, 000 cycles • Attenuation at 1550 nm: 0.25 d B/km • Attenuation at 1310 nm: 0.35 d B/km • Operating Temperature: -20°C to +70°C







...

Perfect for your home office or a large installation project, enhanced CAT5e 350 M Hz Assembled Patch Cables from Cables to Go distribute data, voice & video over today's advanced fast Ethernet & Gigabit computer networks. These cables will handle bandwidth intensive applications up to 350 M Hz & beyond. ...

Product Description Cost-effective solution that provides higher bandwidth & transmission rates & supports longer distances with lower loss than 62.5/125 fibre. Specifically designed for use with today's narrower aperture components, this cable is fully compatible with multimode applications. The Low Smoke Zero Halogen (LSZH / LS0H) jacket is composed from materials that lessen the smoke & halogen emissions when the cable is exposed to extreme temperatures. This reduces the amount of harmful toxic & corrosive gases that cabling made with plastic materials would otherwise emit into the air during combustion. This construction makes LSZH cables ideal to be used where the protection of people & equipment from harmful corrosive gases is absolutely critical. The patented injection moulding process provides each connection greater durability in resisting pulls, strains & impacts from cabling installs. Connectors: • SC Connector Dimensions: 10.6mm Height x 26mm Width x 58mm Depth (with installed duplex clip) Cable: • Optical Multimode 2 (OM2) fibre supporting 500 MHz.km OFL at 850/1300 nm. • Maximum Connector Loss: 0.50 d B • Typical Connector Loss: 0.30 d B • Typical Return Loss: -25 d B • Buffer

Material: PVC • Buffer OD: 900 µm • Jacket

Material: LSZH PVC (OFNR riser-rated) • Jacket OD: 2.8 mm • Installation Tensile Load: 100 N (445 lbs) • Long-Term Tensile Load: 50 N (222 lbs) • Maximum Tensile Load: 100 N/cm • Installation (Loaded) Minimum Bend Radius: 5.0cm (1.97in) • Long-Term (Unloaded) Minimum Bend Radius: 3.0cm (1.2in) • Crush Resistance: 750 N/cm • Impact Resistance: 1, 000 cycles • Flex Resistance: 5, 000 cycles • Attenuation at 1300 nm: 1.0 d B/km • Attenuation at 850 nm: 3.5 d B/km • Operating Temperature: -20°C to +70°C



...

Compliant to USB (Universal Serial Bus) 3.0 Super Speed specifications; connect your Super Speed USB (Universal Serial Bus) peripheral for TEN TIMES the transmission rate of USB (Universal Serial Bus) 2.0! ...

Overview Apple's latest i Mac computers & LED Cinema Displays utilize a new type of video connector called Mini Display Port. This adapter cable converts a Mini Display Port signal for video & audio viewing on an HDMI-equipped display. Connect the adapter cable directly to the computer. Then use your HDMI cable between the adapter & the display, & enjoy computer video content on virtually any high-definition digital video display*. Supports full HD resolution (1080p @ 60 Hz). Connector 1: (1) Display Port Mini Male Connector 2: (1) HDMI (Type A) Port ...

Display Port is a next-generation technology that delivers high bandwidth, pure digital audio/video signals from your PC to your display. Quality-made from 28 AWG copper wire, this cable is designed to deliver sharp, crystal-clear picture & sound, & is fully shielded to protect against EMI/RFI (Aluminium-wrapped, with a copper braid shield). Certified to Display Port 1.1 standards, it supports 10.8 Gbps, 12 bpc (bits per component), 36 bpp (bits per pixel), & has a 120 Hz refresh rate. Nickel-plated connectors; lifetime warranty. Please Note: 1.1 supports a single video source, & our Display Port cables & adapters support this

Specification. For reference, version 1.2, as it occurs in the future, will support multiple video streams for such devices that require the additional bandwidth. Connector 1: (1) Display Port Male Connector 2: (1) Display Port Male
Colour: Black UPC:757120812784 Warranty: Lifetime Weight: 0.104kg Length: 1.00 Meter


...

The Velocity HDMI to DVI-D cable delivers a strong combination of performance & value. It is a high performance home theatre ...

Overview Display Port is a next-generation technology that delivers high bandwidth, pure digital audio/video signals from your PC to your display. Quality-made from 28 AWG copper wire, this cable is designed to deliver sharp, crystal-clear picture & sound, & is fully shielded to protect against EMI/RFI (Aluminum-wrapped, with a copper braid shield). Certified to Display Port 1.1 standards, it supports 10.8 Gbps, 12 bpc (bits per component), 36 bpp (bits per pixel), & has a 120 Hz refresh rate. Nickel-plated connectors; lifetime warranty. Connector 1: Molex (LP4) Male Connector 2: Molex (LP4) Male Please Note: 1.1 supports a single video source, & our Display Port cables & adapters support this

Specification. For reference, version 1.2, as it occurs in the future, will support multiple video streams for such devices that require the additional bandwidth. Connector 1: (1) Display Port Male Connector 2: (1) Display Port Male

...

Overview HDMI High Speed With Ethernet The Velocity HDMI cable delivers a strong combination of performance & value, & is ...

Use this Display-Port to DVI cable to connect a Display-Port source directly to a DVI monitor or display. The passive design will support a 1920 x 1080 resolution up to 3 metres. It is VESA-compliant with transparent operation which will auto-calibrate & configure the signal for minimal configuration. Great for applications when you want to connect a newer laptop or desktop to a DVI-enabled display. Please Note: This Display-Port adapter operates passively & is designed for use with dual mode graphics cards often designated with ?D++?. Although the vast majority of source devices with Display-Port are dual mode, it is recommended that you consult with your computer or graphics card manufacturer to verify compatibility with passive adapters. Connector 1: (1) Display-Port Male Connector 2: (1) DVI-D Single Link Male ...
